Instructions for use Lojer Modux nursing bed / Version 2.5
Copyright © Lojer Oy, 2022 42
When measuring the space between the sleeping surface and the lower
siderail, raise the lower siderail up until it stops.
At the head of the bed, the space between the siderail and the headboard
must not be more than 60 mm. At the foot of the bed, the space between
the siderail and the footboard must be less than 60 mm or more than
318 mm.
The space between the lower siderail and the sleeping surface must not be
more than 120 mm.
The space between the upper and lower siderail (at the centre of the
siderail) must not be more than 120 mm.
The rails must comply with the measurements provided for in standard EN
60601-2-52: 2010. Check that the dimensions of the rails are acceptable
according to the boundary values provided for in the standard (see image
49).
Clean the bed before and after service!
9.6 Changing the power cord
See safety instructions presented in Chapter 9. Obey with following
instructions when changing the power cord.
1. Detach the power cord from mains socket. Proceed with caution if the cord
has any external damages visible (wire insulation, plug etc. damaged).
2. Detach the power cord from strain relief located in the head end of the bed
by using fork wrenches and/or adjustable wrenches. Detach the nut pointed in
image below and string the power cord out from strain relief -support.
Image 50. Detaching the power cord from strain relief
Detach the nut and string the
power cord out from strain
relief -supports’ slot.
