Instructions for use Lojer Modux nursing bed / Version 2.5
Copyright © Lojer Oy, 2022 45
4. Detach hand control units’ plug from the control unit (pointed in image
below).
Image 54. Detachment of hand control from control unit
5. Attach new hand control units’ connector plug to the control unit.
6. Perform stages 3. 2. inversely to attach the strain relief and the
protective cover of the control unit back in place. Make sure that all fastenings
are tightened in suitable tightness: Fastenings has to be tight but not so tight
that components get broken.
7. Plug the power cord into mains socket and ensure correct operation of all
the movements of the bed by using the hand control unit.
Detach hand
controls’ plug
from the control
unit
