11
ii.Names of major parts and components of mini tiller
Figure 1
1. Handlebar assembly 2. Engine assembly 3. Drag bar 4. Transmission box assembly
5. Fender 6. Tilling blade assembly 7. Reduction gear box assembly
7
6
5
4
3
2
1
