LONCIN G200F Shop Manual

G120F/G160F/G200F Part II Description of maintenance
- 21 -
5. Troubleshooting for hard electric starting
Combination switch is open or
faulty
Fuse melted
Starter solenoid faulty
Starter motor faulty
Battery faulty
Battery faulty
Charging coil faulty
Star
ter motor
doesn’t rotate
Battery is unable to
be charged
Inspect P33 (4-2)
Replace
Inspect P40 (4-5)
Inspect P40 (4-5)
Inspect P63 (4-10)
Inspect P63 (4-10)
Inspect P40 (4-5)

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
