LONCIN G200F Shop Manual

G120F/G160F/G200F Part III Maintenance
- 30 -
3-10 Governor
1) Remove the fuel tank.
2) Loosen the hexagon flange nut (M6) of the pointless lag lock screw to move the governor arm
to fully open the throttle.
3) Press on the governor arm at the position where the throttle is fully open and rotate the
governor arm clockwise as far as it will go (to the position where governor is fully closed), then
tighten the nut.
4) Check whether governor support and throttle valve move freely.
5) Check and adjust the gasoline engine’s maximum no-load speed.
a. Start the gasoline engine and allow it to warm up for about 10 minutes.
b. If the gasoline engine’s maximum no-load speed is not as specified, adjust the cross recessed
pan head screw M5×35.
Gasoline engine’s maximum no-load speed 3,850 ± 150 rpm
Speed too high Adjust the adjusting screw counterclockwise
Speed too low Adjust the adjusting screw clockwise
Control lever
Governor
spring
T
hrottle return
spring
Governor limit
spring
Governor rod
Governor arm
Screw M5×35

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
