LONCIN G200F - Page 33

G120F/G160F/G200F Part IV Disassembly and maintenance
- 32 -
2. Disassembly/reassembly of muffler
Muffler protector
M5×8mm cross
recessed pan head
screw（4）
8mm hexagon nut（2）
2.4kg-m
Exhaust pipe gasket
Muffler
Reassembly:
Install after removing the carbon
deposits from the muffler by gently
knocking with a plastic hammer.
