LONCIN G200F Shop Manual

G120F/G160F/G200F Part IV Disassembly and maintenance
- 59 -
2. Inspection
Oil level switch
1) Hold the oil level switch upside down to
confirm there no continuity between yellow
lead and ground wire.
2) Hold the oil level switch in its normal position,
confirm the continuity exists between the
yellow lead and ground wire.
3) Inspect the float by dipping the oil level switch
into a container of oil, confirm there is no
continuity between the yellow lead and ground wire.
(ON)
(OFF)

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
