ENGINE PARAMETER
- 20 -
10. ENGINE PARAMETER
Model 154F-1
Type Single cylinder 4-Stroke Forced air cooling OHV
Rated power
(kW/3600rpm)
1.6Kw/3600rpm
Max power
（Kw/4000rpm）
2.0Kw/4000rpm
Max torque N·m/rpm 4.5N.m/3000rpm
Fuel consumption ratio
(g/kW·h)
≤450
Speed fluctuating ratio ≤10%
Noise ≤ dB(A) 93
Bore×Stroke mm 54×38
Displacement cc 87
Compression ratio 8:5:1
Lubricating mode Splash
Staring mode Recoil start
Rotation Anti-clockwise(from P.T.O.Side)
Valve clearance mm
Intake valve 0.10-0.15
Exhaust valve 0.15-0.20
Spark plug gap mm 0.7~0.8
Ignition mode Transistorized magneto ignition
Air cleaner Single element
Length 310
Width 225
Dimension
mm
Height 305
Net weight kg 10.5
