WIRING DIAGRAMS
- 21 -
11. WIRING DIAGRAMS
Non-electric starting engine with oil protection system
Engine switch WIRING
IG
E ST
BAT
OFF O O
ON
START O O
Transistorized
ignition unit
Engine
switch
Spark plug
