Symbols
Symbols ① to ⑧ indicate the following
① Can be serviced with engine mounted
② Filling fluid
③ Lubricant
④ Special tool
⑤ Torque
⑥ Wear limit, clearance
⑦ Engine speed
⑧ Electrical data (Ω, V, A)
Symbols ⑨ to ⑯ in the exploded diagrams
indicate the types of lubricants and lubrication points.
⑨ Apply engine oil
⑩ Apply gear oil
⑪ Apply molybdenum disulfide oil
⑫ Apply brake fluid
⑬ Apply wheel bearing grease
⑭ Apply lithium-soap-based grease
⑮ Apply molybdenum disulfide grease
⑯ Apply silicone grease
Symbols ⑰ to ⑱ in the exploded diagrams
indicate where to apply a locking agent ⑰ and when
to install a new part ⑱.
⑰ Apply the locking agent (LOCTITE
○R
)
⑱ Replace
