PERIODIC CHECKS AND ADJUSTMENTS
3-14
Tire pressure
Manufacturer Size Pressure
Front KINGSTONE 22 × 7-10
45kpa
6.5psi
Rear KINGSTONE 22 × 10-10
45kpa
6.5psi
① Front Axle Nut
① Rear Axle Nut
• Check the front axle nut for looseness.
• Check the rear axle nut for looseness.
If the axle nuts are loose, tighten them to the
specified torque.
Axle nut
Front：80 N·m(8 m·kg,58 ft·lb)
Rear：200 N·m(20 m·kg,144 ft·lb)
Wheel inspection
Inspect the tire surfaces.
Replace if wear or damage.
Tire wear limit: 3 mm (0.12 in)
Tire wear limit ○
a
Front and rear：3.0 mm (0.12 in)
TIP:
It is dangerous to ride with a worn out tire. When a tire
wear is out of specification, replace the tire immedi-
ately.
• Inspect the wheel.
• Replace if damage or bends
• Always balance the wheel when a tire or
• wheel has been changed or replaced.
TIP:
Never attempt even small repairs to the wheel.
Ride conservatively after installing a tire to allow it
to seat itself properly on the rim.
