LONCIN Xwolf 200 2020 - Covering Parts and Footrest System

BODY
4-3
Covering parts and footrest system
Order Job/Part Q’ty Remarks
1
2
3
4
5
6
Removing the covering parts and footrest
system
Seat/front fender
Foot rest
Left pedal
Right pedal
Fuel tank cover
Left side cover
Right side cover
2
1
1
1
1
1
Remove the parts in the order listed.
Refer to “FRONT/REAR CARGO RACK AND
SEAT” and “FRONT FENDER”
TIP:
During removal, do not pull the joint claws
forcedly to avoid damage.
