LONCIN YF300 User Manual

35
Remove clutch and driving gear
Remove pushing rod
Remove pushing plate
Loosen locking nut on clutch
Screw off locking nut on primary driving gear
Remove clutch component
Remove collar and flat washer on clutch
Remove primary driving gear
Remove semi-round key
Disassemble clutch
Loosen spring bolt
Remove lifting plate, spring and center case
Remove driving plate（with friction material）and
driven plate（steel plate）
Check clutch
Check thickness of driving plate by vernier
caliper：
Standard： 2.92～3.08
Limit：2.7
Pushing rod
Pushing plate
Locking nut
Bolt
Spring
Center case
Lifting plate
