5
2 SYSTEM REPORT FORM
System and Components
System Voltage V
Date of Purchase
Purchased from
Battery System? yes no
if not: Quantity of Solar Modules (panels)
Solar Module Brand
Module Model #
Controller Model PS1200 or PS1800
PS600
PS200
other, i.e.:
Controller Serial #
Pump End Model #
Pump End Serial #
Temperature Range
Helical rotor pumps (without C in the model number) work optimally only in a specific
temperature range. Last digit of Pump End Model # indicates temperature class.
If a special temperature range was not specified, the last digit of model number (X) will be 1.
Class 0 32 °F to 54 °F 0 °C to 12 °C
Class 1 46 °F to 72 °F 8 °C to 22 °C Class 1 is the standard class.
Class 2 64 °F to 90 °F 18 °C to 32 °C
Class 3 82 °F to 108 °F 28 °C to 42 °C
Class 4 100 °F to 126 °F 38 °C to 52 °C
See Section 12
for more about
temperature
specifications.
