Product Information 1514 Product Information
EN EN
4.5 Storage of pump system components
Prolonged intermediate storage in an environment
of high humidity and uctuating temperatures must
be avoided. Moisture condensation may damage
metal parts. Non-compliance can void the warranty.
It is recommended to store the parts in a closed and
dry room. The pump system must not be stored or
operated where the average day humidity is above
80%. The motor, the pump end and controller can be
stored (not used) in the range of –20°C to +65°C (–4°F
to +149°F). The components should not be exposed
to direct sunlight.
for CS-G pumps
CS
- G 100 - 22 / 2
motor poles
rated ow (m³/h)
DN of inlet and outlet
single stage pump with
cast housing
centrifugal surface
4.6 Scope of delivery
Scope of delivery
#
Item
Quantity
1
PSk3 controller
1 unit
2
Sun Sensor module
1.5 Wp
1 unit
3
Cable gland reducer
2 units
4
Manual
1 unit
Check upon receipt that the packaging is undamaged
and complete. If any abnormity is found, contact
your supplier.
LORENTZ pumps are supplied from the factory in
proper packing in which they should remain until
they are to be installed at the site. Handle the pump
with care and avoid unnecessary impacts and
shocks.
4.4 Naming convention
A PSk3 pump system name consists of two
components. The rst component refers to the
pump systems controller while the second part
refers to the pump model. A detailed overview about
the pump model naming can be found below.
Pump model denition
for C-SJ8-44 to C-SJ75-4 submersible pumps
C
- SJ 12 - 9
number of impellers
rated ow (m³/h)
submersible
centrifugal
for C-SJ150-2-2 pumps
C
- SJ 150 - 2 - 2
number of small
impellers
number of impellers
rated ow (m³/h)
submersible
centrifugal
Pump model denition
for CS-F12 to CS-F20 surface pumps
CS - F 12 - 9
stages
rated ow (m³/h)
vertical multistage
pump
centrifugal surface
for CS-F32 to CS-F85 pumps
CS - F 32 - 60 - 2
number of small
impellers
stages ×10
rated ow (m³/h)
vertical multistage
pump
centrifugal surface
