SYSTEM
Operating System Linux (embedded)
Pentaplex Simultaneous View, Record, Playback, Backup & Remote Monitoring
Number of Channels 16 Channel
Inputs/Outputs
Video IN 16 x 1Vp-p, CVBS, 75ohms, BNC/DIN
Video OUT 2 x BNC
VGA OUT Yes
Audio IN 16 Line in(BNC), ADPCM(16 ch)
Audio OUT 2 line out(BNC), ADPCM(16 ch)
USB Port 2 at the back
Alarm IN 16 ch IN
Alarm OUT 16 ch OUT
PTZ control RS-485 Pelco D & P Protocol
Display
Live Display 16 ch: 1, 4, 8, 16
Live Display Speed 120 (4 ch)/ 240 (8 ch)/ 240 (16 ch) NTSC
100 (4 ch)/ 200 (8 ch)/ 200 (16 ch) PAL
OSD ON/OFF
System Navigation USB Mouse, IR Remote Controller, Front Panel
Motion Area Setting Adjustable grid (10 x15) NTSC
Adjustable grid (12 x15) PAL
Sensitivity levels 8
Firmware Upgrade Via USB device
User Authority By user group
Time Synchronization Auto time sync by NTP server
RECORDING
Video Compression H.264
Audio Compression ADPCM
Recording Resolution NTSC: 360x240 (CIF), 720x240 (HD1), 720x480 (D1)
PAL: 360x288 (CIF), 720x288 (HD1), 720x576 (D1)
Recording Speed: 16 ch: 480/400 (NTSC/PAL) @ CIF, 240/120(NTSC/PAL) @
HDI, 120/100 (NTSC/PAL) @ DI
Recording Resolution Setting Per camera for different resolutions (CIF/2CIF/D1)
Recording Quality Control 3 levels
Image Size 768-1536 Kbyte (D1), 512-768 Kbyte (HD1) , 384-512 Kbyte
(CIF)
Recording Schedule By hour, by day, by recording mode, by alarm, by ch
Pre Recording Max. 10 Secs
Post Recording Max. 5 Minutes
Reliability Watch-Dog, Auto-recovery after power failure
Covert Video Yes
Image Sensor: High Resolution 1/4” Advanced Color Image Sensor
Video Format: NTSC
Effective Pixels: H: 656, V: 492
Resolution: 420 TV Lines
Scan System: 2:1 Interlace
Sync System: Internal
S/N Ratio: More than 48dB
Iris: AES
AES Shutter Speed: 1/60~1/50,000 Sec
Mini Illumination: 0.6 Lux without IR LED, 0 Lux with IR LED
Video Output: Composite 1.0Vpp @ 75 ohm
Lens/Lens Mount: 5.1mm F 2.8/ Fixed
FOV (Diagonal): 50 degrees
Termination: BNC Type
IR LED/ Night Vision Range: 18 pieces / 850 nm / 40ft/12m
Power Requirement: 12V DC
Power Consumption: 250 mA or 3W max
Operating Temp Range: -10° ~ 50° C
Environmental Rating: IP 66
LH110 ECO SERIES
DVR & CAMERA SPECIFICATIONS
CAMERA CVC6930:
PLAYBACK
Playback Channel 1,4,8,16 (16 ch)
Playback Speed Variable Max 16x
Playback Players Backup Player
Search By time & event
Log Search Up to 10,000 lines for user login/out, configuration
changes, remote access, connects/disconnects
Audio Play Yes
STORAGE & ARCHIVE
Storage 16 ch: Up to 2 HDD’s (SATA)
Maximum Capacity 16 ch: Up to 2 x 2 TB
Backup Media USB Flash Drive & HDD
Backup File Format H.264 file (AVI generator included)
CONNECTIVITY
Easy Connect Lorex Auto Port Forward Wizard
Supported Operating Systems Windows™ XP, Vista, 7
Browsers Internet Explorer
Email notification Text with snapshot
Instant Smart Phone Compatibility† Instant Smart Phone Compatibility on iPhone™,
BlackBerry (supported model numbers: 9700,
9000), Android (version 1.5 & above), Window
Mobile (6.0, 6.5), Symbian 3rd & 5th generation
phones.
DDNS Free Lorex DDNS
System Configuration Full setup configuration over network
Ports Programmable by User
Network Protocol LAN, DHCP, Dynamic IP, DDNS
Network Interface 10/100-Base-TX, RJ-45
Network Speed Control 48Kb ~ 8MB/sec.
GENERAL
Power Consumption 16 ch: Approx. 15 watts
Supply Voltage 16 ch: 100VAC-240VAC, 12VDC , 5A, 50/60Hz
Unit Dimensions 16 ch:14.96” /380mm x13.39”/340mm x
1.97”/50mm
Unit Weight (KGs) 16 ch: 3 kg/6.6 Lbs
Operating temperature 32° ~ 104° F / 0° ~ 40° C
Humidity 10 ~ 90% NC
CAMERA CVC6950:
Image Sensor: High Resolution 1/4” Advanced Color Image Sensor
Video Format: NTSC
Effective Pixels: H: 656, V: 492
Resolution: 480 TV Lines
Scan System: 2:1 Interlace
Sync System: Internal
S/N Ratio: More than 48dB
Iris: AES
AES Shutter Speed: 1/60~1/50,000 Sec
Mini Illumination: 0.6 Lux without IR LED, 0 Lux with IR LED
Video Output: Composite 1.0Vpp @ 75 ohm
Lens/Lens Mount: 5.1mm F 2.8/ Fixed
FOV (Diagonal): 50 degrees
Termination: BNC Type
IR LED/ Night Vision Range: 18 pieces / 850 nm / 50ft/15m
Power Requirement: 12V DC
Power Consumption: 250 mA or 3W max
Operating Temp Range: -10° ~ 50° C
Environmental Rating: IP 66
