Bracket mounting Panel mounting
3
1
2
4
1 2
4 5
Material 10# screw
Soft materials e.g. Plywood Ø 3.7-4.0 mm (5/32”)
Hard materials e.g. Fiberglass, Acrylic, Hardwoods Ø 4.1-4.7 mm (3/16”)
Recommended pilot holes.
3
See panel mounting template for drilling and cutting details.
Panel mounting kit is sold separately.
