HOOK2 4x Sonar | Quick Guide - EN
Pages
• Toggle between the Sonar and the
Flasher pages by pressing the Pages
key
• Zoom the sonar image by using the
Zoom keys
By default the unit is set to Auto mode, and all settings are automated.
• Change to Custom mode to allow for customizing the settings.
Overlay data
By default, 3 data items are displayed on the image. The data items are
predened (depth, temperature and voltage), and the position is xed.
The data items can be turned on/o from the System Controls dialog.
Each data item can be removed individually from the image:
1. Select the Edit overlay option in the System Controls dialog to turn
the unit into edit mode
2. Press the Menu/Enter key to display edit options
3. Press the X key to leave edit mode
Settings dialogs
Used for system conguration.
Product manuals
For the full Operator manual, technical specications and declarations refer to the
product website: www.lowrance.com.

Lowrance HOOK2 Specifications

General

Waterproof Rating	IPX7
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Sonar Type	CHIRP
Frequency	200kHz
Power Output	200 W (RMS)
Depth Capability	Up to 500 ft (152 m)
GPS	Yes (on some models)
Weight	Varies by model
Display Size	4" or 5" or 7"
