The unit can only operate if it is connected to the mains by its supply cable and provided the ON switch has been
actuated and the green voltage light is on When the unit is switched on, the pump starts to run automatically for
about ten seconds for priming.
1
description
of the unit
auxiliary
head hose
access door to filters
and maintenance kit
articulating arm
for main head
air inlet for
ventilation
protection strip
gripping area
for raising the unit
main treatment head
main head hose
drawer for storing
the auxiliary heads
keymodule
pivoting wheels
gripping area for
moving the unit
connection
of auxiliary
treatment head
articulating
arm for
auxiliary head
adjustable mobile
arm rods
air outlets from
ventilation circuit
electrical
cable support
on/off switch
main’s filter
and fuse holder
access door
to technical
elements
electrical cable
data plate
BEFORE USE MAKE SURE THAT THE SUPPLY CABLE IS COMPLETELY UNWOUND
Access to the filters
auxiliary head filter
main head filter
maintenance kit
control
panel
Cellu M6
®
Keymodule [2]i
1
description of the unit
6 7
Drawer for storing the
series 600 auxiliary heads
Cellu M6 Keymodule [2]i
Cellu M6 Keymodule i*
!
* The auxilary heads are replaced by the 600 series auxilary heads.
monitor screen
