Chapter 2. System Configuration
2-11
(2) 1:n Communication system
(a) Using RS-485 built-in function can connect between one computer and multiple main units for up
to 32 stations.
(b) Using RS-485 built-in function/expansion Cnet I/F module can be connect for up to 32 stations.
1) Refer to ‘XGB Cnet I/F user manual’ for details
Note
Max. 32 stations available
PADT connection
Built-in RS-232C connection
XEC-DN32H
Max. 32 stations available
XEC-DN32H
PADT connection
Built-in RS-232C connection
XBL-C41A
XEC-DN32H
XBL-C41A
XEC-DN32H
Max. 32 stations available
Max. 32 stations available
