Chapter 4. CPU Specifications
4-1
Chapter 4 CPU Specifications
4.1 Performance Specifications
The following table shows the general specifications of the XGB main module type
Items
Specifications
Remark
XEC-
DR32H(/D1)
XEC-
DR64H(/D1)
XEC-
DN32H(/DC)
XEC-
DN64H
XEC-
DP32H
XEC-
DP64H
Numb
er of
instructi
ons
Operator 18
Basic function
136 + Real number operation function
Basic function block 43
Dedicated function
block
Special function dedicated function
Processing speed
(Basic instruction)
OS Version less than V5.00 : 83ns/step
OS Version V5.00 or later : 60ns/step
Program memory capacity
OS Version less than V5.00 : 200KB,
OS Version V5.00 or later: 250KB
(Equivalent to XGI 110KB based on maximum capacity)
Max. I/O points 352 384 352 384 352 384
Data
memory
Automatic variable (A) 32KB (Max. 16KB retain setting available)
Input variable (I) 2 KB (%IX15.15.63)
Output variable (Q) 2 KB (%QX15.15.63)
Direct
variable
M 16KB (Max. 8KB retain setting available)
R 20KB (1block)
W 20KB Same area with R
Flag
variable
F
2KB
System flag
K 8KB Built-in special flag
L 4KB High speed link flag
N 10KB P2P flag
U 1KB Analog flag
Flash area 20KB, 2 block R device used
Timer No limit to the number of point (time range: 0.001s ~ 4,294,967,295s)
20 byte automatic
variable area occupied
per r point
Counter No limit to the number of point (count range: 64 bit expression range)
Operation mode RUN, STOP, DEBUG
Restart mode Cold, Warm
Total number of program block 128
Task
Initialization 1
Fixed period
8
External input 8 (%IX0.0.0 ~ %IX0.0.7)
Internal device 8
Self diagnosis
Detecting operation delay, memory error, I/O error
Data reserved in case of power
cut
Setting retain area at basic parameter
Number of max. extension
stage
10 stage
Internal consumption current 660mA 1,040mA 260mA 330mA 300mA 380mA
Weight 600g 900g 500g 800g 500g 800g
