Constitution of the frame sent from Server to Master in response;
④
④④
④ Write Multiple Register
The function used to change from 1 to 16 of the Inverter (Server) data
consecutively.
Constitution of the frame requested from Client to Server;
Constitution of the frame sent from Server to Master in response;
Response Frame
Length Value
Function code 1 Bytes 0x06
Comm. address 2 Bytes 0x0000 ~ 0xFFFF
Data Value 2 Bytes 0x0000 ~ 0xFFFF
Requested Frame
Length Value
Function code 1bytes 0x10
Comm. address 2bytes 0x0000 ~ 0xFFFF
The number of
data to revise
2byte
1~16
(LSIS Inverter standard)
Byte Count 1byte 2 X The number of data
Data value to
revise
The number
of data
x 2 bytes
Data to revise
Response Frame Length Value
Function Code 1 Bytes 0x10
Comm. address 2 Bytes 0x0000 ~ 0xFFFF
The number of
data to revise
2 Bytes
1~16
(LSIS Inverter standard)
