6. Air Conditioning System (Cabin type)
6-1. The name of each part of cooling and heating system
▶ Maintenance of the air conditioning system components (Compressor, Condenser,
Heater evaporator unit and connection parts) must be performed in the designated
dealer. DO NOT disassemble the components arbitrary.
Heater evaporator unit
Compressor
Quick
coupler
Heater hose
Cooler hose
Condenser
Caution
