7 -2
(2) How to use Air-gun system
z Start engine and apply the parking brake.
z Press the upper part of the air-gun switch to turn
on the air-gun system.
z Set engine speed over the 1500 rev/min.
z Once required pressure has been reached a
loud “pop” will be heard, signifying that the
unload valve has opened to allow excess
pressure to escape to atmosphere.
z After connecting the air-gun to quick coupler,
pull the trigger. The quick coupler for air-gun is
installed on the front side of the air-tank and on
the left internal trim inside the cabin.
z After using the air-gun system, turn off the air-
gun switch.
Air-gun switch
Air-gun coupler
Air-gun coupler
