Upper coupler (when pulling)
(3) Remote control lever and Quick coupler (if fitted)
※
This is used to operate the implement (i.e. Dump trailer, Hydraulic conversion plough, etc) attached
to the tractor by the hydraulic pressure.
If you pull the remote control lever backward, the hydraulic pressure works to the upper coupler, and
the lower coupler is connected to the drain.
Each lever of the remote control valve operates respectively and when operating the levers at the
same time, the one received less force begins to start first.
Pull
Lower coupler (when pushing)
Remote control lever
(optional, 1 or 2 valve)
Push
3
3 3
3 - 18
