2. The Name of Each Part

(1) Roll-bar type

Safety frame

(Roll bar)

Hood

(Bonnet)

Steering wheel

Driver’s seat

Fuel tank

Instrument panel

Fender

2 2

2 - 1

Headlight

Tire

Sub step

Front weight

Bumper
