MAINFRAME ASSEMBLY
REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40231069 BT664-11000-05 MAIN FRAME ASS'Y 1
2 40231065 BT651-52100-01 CROSS BAR 1
3 40231088 BT664-62100-02 STABILIZER ASS'Y-RH 1
4 40231086 BT664-61100-02 STABILIZER ASS'Y-LH 1
5 40231087 BT664-61200 FOOT PLATE 2
6 40231064 BT651-31600 BRACKET-CUSHION 2
7 40230876 1002-B004 CUSHION 2
8 40231066 BT651-75110-03 BUSHING, 405030 2
9 40231089 BT664-71100 PIN,∅25-171L 4
10 40231090 BT664-71200 PIN,∅25-139L 2
11 40231091 BT664-71300 PIN,∅25-175L 2
12 40231104 BT664-72800-02 STABILIZER LOCK 2
13 40231105 BT664-73120 WASHER 2
14 40230885 10121-M1004-90 HEX.BOLT,M10-1.5P 90L 2
15 40228641 10316-M1000 WASHER-SPRING,M10 2
16 40230877 1002-B005 RUBBER STOP 2
17 40231035 BH09-0117 U-BOLT,∅40,5/16-18 1
18 40228607 10121-M0803-50 HEX.BOLT,M8-1.25P 50L 8
19 40230896 1021N-M0803 NUT-SELFLOCK,M8-1.25P 8
20 40228634 1021N-M1004 NUT-SELFLOCK,M10-1.5P 4
21 40230901 1202-0361 HEX.NUT,5/16 4
22 40230888 10121-M1606-60 HEX.BOLT,M16-2.0P 60L 4
23 40228644 10316-M1600 WASHER-SPRING,M16 4
24 40228636 1021N-M1606 NUT-SELFLOCK,M16-2.0P 4
25 40230883 10121-M1004-50 HEX.BOLT,M10-1.5P 50L 2
26 40228647 10321-M1000 WASHER-PLAIN,M10 4
27 40231034 BH07-0113 SPRING 2
28 40230956 802G0-11900 NIIPPLE GREASE,PT1/8 8
29 40230957 802G1-11900 NIIPPLE GREASE,PT1/8 45˚ 8
