LS tractor MT2 25S - Page 101

4 -21
MID PTO 1 speed gear (15T)
PTO / Engine speed 2500 / 2647 rpm
Rotation direction Counter clockwise (When looking at PTO shaft end)
Shaft dimension
(Unit : inch)
③ Specification and Dimension of Middle PTO shaft
- Spline Teeth: 15T (Where fitted)
Module : DP 16/32
Number of Teeth : 15T
(0.84 in.)
(0.98 in.)
(1.89 in)
(0.94 in)
(1.54 in)
