A
djusting Engine V
alve
clearance
Ask your authorized
dealer
to check
the valve
clearance.
Clearance
: 0.25mm (0.0098
inch)
If the
gap
is big, the
noise increase and
if the
gap
is
small, the
engine
pow
er can be
low
.
0.
2
5
m
m
(5) Checking
Nozzle injection
pressure
Contact
your authorized
dealer.
Normal injection
pressure
: 14.7
MPa (2132psi)
(All models)
5
5
5
5
-
2
4
104
106
