(7) Error Diagnosis Code (EZ-Shift)
If the sensor or actuator relating to the EZ-Shift
system has failed, the error code shall be
displayed on the Instrument panel as shown in
the right figure.
In case of several errors, the errors shall be
displayed repeatedly every 1 second. In this
case, record all error codes.
And, contact your authorized dealer for check
and tell the error codes.
Code Number
A : N/A
B : EZ-Shift
Error code Description
B01 Electro-magnetic brake error
B11 Electronic horn (Buzzer) error
B21 EZ-Shift shuttle lever circuit cut-off
B22 EZ-Shift shuttle lever circuit short
B03 Clutch actuator motor error
B13 Clutch actuator encoder error
B23 Clutch actuator potentiometer circuit cut-off
B24 Clutch actuator potentiometer circuit short
B32 Forward-reverse actuator potentiometer circuit cut-off
B33 Forward-reverse actuator potentiometer circuit short
B34 Forward-reverse gear engagement error
B35 Electro-magnetic brake life cycle over
