LS iP5A - Standard Specifications - Part 2; 380~480 V Class Specifications (50-125 HP); 525~600 V Class Specifications

iP5AiP5A
Standard Specifications
380~480V Class (110~450kW / 50~125HP)
Model Number (
SV iP5A-4
)
1100 1320 1600 2200 2800 3150 3750 4500
178 210 259 344 436 488 582 699
150 200 250 350 400 500 600 700
110 132 160 220 280 315 375 450
223 264 325 432 547 613 731 877
110% 1 Minute (Normal Duty)
125 150 200 250 350 400 500 600
90 110 132 160 220 280 315 375
183 223 264 325 432 547 613 731
150% 1 Minute (Heavy Duty)
0.01~120 Hz
380~480V
3
Ø
380~480V (-15%~+10%)
50/60 Hz (± 5%)
IP00 / UL Open
Built-in External Option
101 (222.7) 101 (222.7) 114 (251.3) 200 (441.9) 200 (441.9) 243 (535.7) 380 (837.7) 380 (837.7)
Note3)
Note4)
Capacity [kVA]
Motor rating
(HP)
Fan or (kW)
pump load Current [A]
(110% over current)
Output
Motor rating
(HP)
ratings General (kW)
load Current [A]
(150% over current)
Frequency
Voltage
Input Voltage
ratings Frequency
Protection degree
DCL
Weight [kg (lbs.)]
Note1)
Note2)
525~600V Class (5.5~110kW /7.5~150HP)
Model Number (
SV iP5A-6
)
055 075 110 150 185 220 300 370 450 550 750 900 1100
9.6 12.7 19.1 23.9 31.1 35.9 48.6 59.8 72.5 87.6 121.1 145.8 178
7.5 10 15 20 25 30 40 50 60 75 100 125 150
5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
9 12 17 23 27 34 43 55 64 80 104 128 150
110% 1Minute (Normal Duty)
5.5 7.5 10 15 20 25 30 40 50 60 75 100 125
3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
6.1 9 12 17 23 27 34 43 55 64 80 104 128
150% 1 Minute (Heavy Duty)
0.01~120 Hz
525 ~600V
3f 525~600V (-15% ~ +10 %)
50/60 Hz (±5 %)
IP20 / UL Type1 IP00 / UL Open
6.5 7.0 7.0 11.7 11.7 18.9 18.9 32 32 32 46 46 101
(14.4) (15.5) (15.5) (25.8) (25.8) (41.7) (41.7) (70.65) (70.65) (70.65) (101.5) (101.5) (223)
Note3)
Note4)
Capacity [kVA]
Motor rating
(HP)
Fan or (kW)
pump load Current [A]
(110% over current)
Output
Motor rating
(HP)
ratings General (kW)
load Current [A]
(150% over current)
Frequency
Voltage
Input Voltage
ratings Frequency
Protection degree
Weight [kg (lbs.)] Standard Type
Note 1) Rated capacity (v 3
X
V
X
I) is based on 220V for 200V class and 460V for 400V class. 2) Indicates the maximum applicable capacity when using a 4-Pole LS motor.
3) Maximum output voltage will not exceed the input voltage. An output voltage less than the input voltage may be programmed if necessary.
4) IP20/UL Type1 with optional conduit, it can be modified to UL Type1.
