Industrial Drive for Fan and Pump STARVERT iP5A
(1) Rated capacity (√3×V×I) is based on 220V for 200V class and 460V for 400V class. (2) Indicates the maximum applicable capacity when using a 4-Pole standard motor.
(3) IP20 or UL Enclosed Type1 can be provided by the option. (4) IP20 or UL Enclosed Type1 is not provided.
(5) Overload rating 120%, 1 min is based on ambient 25
℃
Forced air cooling (Self-cooling for below 1.5kW-2, 2.2kW-4)
V/F, Sensorless Vector, Slip Compensation, Easy Start Selectable
Digital Reference: 0.01 Hz (Below 100 Hz), 0.1 Hz (Over 100 Hz)
Analog Reference: 0.01 Hz / 60 Hz
Digital: 0.01% of the max frequency
Analog: 0.1% of the max frequency
Linear, Squared Pattern, User V/F
110% per 1 min, 120% per 1 min
Note5)
Manual Torque Boost (0 ~ 15 %), Auto Torque Boost
Keypad / Terminal / Communication Operation
Analog: 0 ~ 12V / -12V ~ 12V / 0~20mA/ Pulse / Ext-PID
Digital: Keypad
Forward, Reverse
Up to 18 Speeds can be set including Jog (Use Programmable Digital Input Terminal,Including Jog/Dwell )
0.1~ 6,000 sec, Max 4 types can be set via Multi- Function Terminal. Accel/Decel Pattern: Linear,
U-Curve, S-Curve Selectable
Interrupts the Output of Drive
Jog Operation
Fault Reset
Frequency Detection Level, Overload Alarm, Stalling, Over Voltage, Low Voltage, Drive Overheating/
Running/ Stopping/ Const ant running, Drive By-Pass, Speed Searching
Contact Output (3A, 3C, 3B) - AC 250V 1A, DC 30V 1A
Choose 2 from Output Frequency, Output Current, Output Voltage, DC Link Voltage
(Output Voltage: 0 ~ 10V)
DC Braking, Frequency Limit, Frequency Jump, 2
nd
Function, Slip Compensation, Reverse Rotation
Prevention, Auto Restart, Invert By-Pass Auto-Tuning PID Control Start Stop Braking leakage Pre-PID
Dual-PID MMC Start Prer By Pass, Auto Tuning, Control, Flying Start, Safety Stop, Flux Braking,
Low leakage, Pre PID, Dual PID, MMC, Easy Start, e-heater
Over Voltage, Low Voltage, Over Current, Ground Fault, Drive Overheat, Motor Overheat, Output Phase
Open, Overload Protection, External Fault 1, 2, Communication Error, Loss of Speed Command,
Hardware Fault, Option Fault etc
Stall Prevention, Overload Alarm, Thermal Sensor Fault
Output Frequency, Output Current, Output Voltage, Frequency Set Value, Operating Speed, DC Voltage,
Integrating Wattmeter, Fan ON time, Run-time, Last Trip Time
Trips Indication when the Protection Function activates.
Max. 5 Faults are saved.
Last Trip Time.
-10
℃
~ 50
℃
(14
℉
~ 122
℉
)
Decrease 2% of rated current for every 1℃ increase in above 40℃
-20
℃
~ 65
℃
(-4
℉
~ 149
℉
)
Below 90 % RH Max. (Non-Condensing)
Below 1,000m (From 1000 to 4000m, the rated input voltage and rated output current of the drive must be
derated by 1% for every 100m.), Below 5.9m/sec2 (0.6g)
Pollution degree 2, No Corrosive Gas, Combustible Gas, Oil Mist, or Dust
Common Specifications
Cooling method
Control Method
Frequency Setting Resolution
Frequency Accuracy
V/F Pattern
Overload Capacity
Torque Boost
Operation Method
Frequency Setting
Start Signal
Multi-Step
Multi Step Accel/Decel Time
Emergency Stop
Jog
Fault Reset
Operating Status
Fault Output
Indicator
Operation Function
Drive Trip
Drive Alarm
Operation Information
Trip Information
Ambient Temperature
Storage Temperature
Ambient Humidity
Altitude-Vibration
Application Site
Keypad
Output signal
Input Signal
Environment
Display
Protection
Operation Control
