LS iP5A - Standard Specifications - Part 1; 200~230 V Class Specifications; 380~480 V Class Specifications (1-125 HP)

Industrial Drive for Fan and Pump STARVERT iP5A
Standard Specifications
Note 1) Rated capacity (v 3｡｡V｡｡I) is based on 220V for 200V class and 460V for 400V class. 2) Indicates the maximum applicable capacity when using a 4-Pole LS motor.
3) Maximum output voltage will not exceed the input voltage. An output voltage less than the input voltage may be programmed if necessary.
4) IP20/UL Type1 with optional conduit, it can be modified to UL Type1.
380~480V Class (0.75~90kW / 1~125HP)
Model Number (
SV iP5A-4
)
008 015 022 037 055 075 110 150 185 220 300 370 450 550 750 900
2.0 3.2 4.8 6.4 9.6 12.7 19.1 23.9 31.1 35.9 48.6 59.8 72.5 87.6 121.1 145.8
1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
2.5 4 6 8 12 16 24 30 39 45 61 75 91 110 152 183
110% 1 Minute (Normal Duty)
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
1.25 2.5 4 6 8.8 12 16 22/24 28/30 34/39 44/45 - - - - -
150% 1 Minute (Heavy Duty)
0.01~120 Hz
380~480V
3
Ø
380~480V (-15%~+10%)
50/60 Hz (± 5%)
IP20 / UL Type1 IP00 / UL Open
4.1(9.0) 4.2(9.3) 4.2(9.3) 4.9(10.8) 4.9 (10.8) 6 (13.2) 6 (13.2) 12.5 (27.6) 13 (28.7) 20 (44.1) 20 (44.1) 27 (59.5) 27 (59.5) 29 (64) 42 (92.6) 43 (94.8)
- - - - - - - 19.5 (43.9) 19.5 (42.9) 26.5 (58.3) 26.5 (58.3) 39 (86) 40 (88.2) 42 (92.6) 67 (147.4) 68 (149.9)
Note3)
Note4)
Capacity [kVA]
Motor rating
(HP)
Fan or (kW)
pump load Current [A]
(110% over current)
Output
Motor rating
(HP)
ratings General (kW)
load Current [A]
(150% over current)
Frequency
Voltage
Input Voltage
ratings Frequency
Protection degree
Weight [kg (lbs.)]
Standard Type
Built-in DCL Type
Note1)
Note2)
200~230V Class (0.75~30kW / 1~40HP)
Model Number (
SV iP5A-2
)
008 015 022 037 055 075 110 150 185 220 300
1.9 3.0 4.6 6.1 9.1 12.2 17.5 22.9 28.2 33.5 43.8
1 2 3 5 7.5 10 15 20 25 30 40
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30
5 8 12 16 24 32 46 60 74 88 115
110% 1 Minute (Normal Duty)
0.5 1 2 3 5 7.5 10 15 20 25 30
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
2.5 5 8 12 17 23 33 44 54 68 84
150% 1 Minute (Heavy Duty)
0.01~120 Hz
200~230V
3
Ø
200~230V (-15%~+10%)
50/60 Hz (± 5%)
IP20 / UL Type1 IP00 / UL Open
4.1(9.0) 4.2(9.3) 4.2(9.3) 4.9(10.8) 4.9 (10.8) 6 (13.2) 6 (13.2) 13 (28.7) 13.5 (29.8) 20 (44.1) 20 (44,1)
Note3)
Note4)
Capacity [kVA]
Motor rating
(HP)
Fan or (kW)
pump load Current [A]
(110% over current)
Output
Motor rating
(HP)
ratings General (kW)
load Current [A]
(150% over current)
Frequency
Voltage
Input Voltage
ratings Frequency
Protection degree
Weight [kg (lbs.)]
Note1)
Note2)
9
Drive Starvert iP5A Series
