LS iP5A - Page 7

Easy Start
When pushing ‘STOP’ key for
2~3 seconds in case drive
turns on, the drive turns into
‘Easy Start Mode’ with FWD,
REV, and STOP command.
‘SHIFT/ESC’ can return it to
previous mode.
Control method: V/F
Control frequency: Jog
User-friendly Keypad & Easy Maintenance
NPN/PNP Input
iP5A has both NPN and PNP input, and you can select
one of them easily.
Abundant I/O Suggestion
iP5A serves abundant I/O.
Various Units of I/O Display
The iP5A display can be calibrated in many different types
of process units.
Built-in RS485 and Optional Communication
The built-In RS485 allows for communication without external option.
However, the optional communication boards enable the iP5A to talk
to BMS and most Industrial Systems
Long-life Condenser and Simple Framework
iP5A adopts long-life condenser and enables easy maintenance in
simple framework.
Consumption Time Display
iP5A displays consumption time of components so that users can
replace them in time.
Others
•
Removable terminal board
•
External fan available
•
Cooling fan on/off control
3
1 4
5
6
7
2
3
8
4
1
2 6
The iP5A construction allows for easy maintenance, with ease-of-access to all components.
5
7 9
Digital Input/Output
Analog Input (Voltage + Current)/Output
Pulse Input
NTC/PTC Input
8 points / 4 points
(1+1) points /4 points
1 point
1 point
Industrial Drive for Fan and Pump STARVERT iP5A
