11ASSEMBLY INSTRUCTIONS |
STEP 4
1. Place (#11) into part (#13) and (#14) as shown above.
2. Set (#79), (#16), (#79) and (#13) into (#12) in order as pictured and do the same for the other side.
3. Once you have set (#12) into (#13) and (#14) according to the drawing, insert the lower end of (#12)
into the (#2) and (#3) frame holes.
11
14
79
15
12
13
16
79
12
To Next Page
