12 | ASSEMBLY INSTRUCTIONS
STEP 5
1. Install (#17) into the (#2) hole as shown.
2. Then insert (#79) into (#17) and insert the weight stacks (#68) one by one.
(NOTE: the weight stack groove is facing down).
3. Insert block (#68) into (#17) and place (#19) in the middle hole of the blocks.
4. Insert the counterweight head (#69) into (#17), and then insert (#18) into (#17). Select a suitable hole
to insert into (#80) pin.
5. Place the sleeves (#77) into (#18) as shown. Then insert (#78) onto (#77) sleeve.
6. Repeat for the other side.
NOTE: The direction of the gap in the counterweight must be face downward.
17
77
77
18
78
69
17
19
68
19
18
77
68
69
79
80
