LSG GRK200 - Page 13

13
STEP 6
1. Place (#21) onto (#10) as shown and secure with bolts (#93), flat pads (#99), nuts (#100).
2. Install (#22) and (#23) onto (#20) as shown and secure them with bolt (#94) and flat spacers (#99).
3. Place the installed (#20) as shown in the figure. Then place (#5) and (#6) on both sides of the posts,
and tighten with bolts (#92), flat spacer (#99) and nuts (#100).
ASSEMBLY INSTRUCTIONS |
23
22
20
99 94
6
93
99
57
21
5
99
100
99
92
100
