S100/H100 Conduit Option Installation Manual
3.4 H100 0.8~30kW
Remove the Power cover and cable guide of the product as shown in the Figure 10.
Figure 10. Remove Power Cover and CABLE Guide
Fasten the Conduit Option to fit on the side of ground terminals of the product using the prescribed bolt as
shown in the Figure 11.
Figure 11. Install
11
