MXD70 Setpoints, Current Outputs, and
Digital Inputs Configuration Guide
Setpoint Alarm Mode
By Selecting Alarm in the setpoints input source the setpoint can be configured as an alarm output
triggered by one of a number of events.
Sensor Error –
When a sensor related error is detected on the associated sensor input
channel.
Dose Alarm –
When any of the dose alarms active on a setpoint associated with this
setpoints sensor input channel.
Calibration –
When a calibration is in progress on the associated sensor input channel.
Off-Line –
When the associated sensor input channel has been taken “Off-Line.”
Any Error –
When any error is detected on the associated sensor input channel.
Cleaning –
When a cleaning operation is in progress on a setpoint associated with
this setpoints sensor input channel.
Calibration Due –
When if enabled the calibration due timer has expired on the associated
sensor input channel.
Gain Error –
When a gain error is present on the associated sensor input channel.
Only available when set to a suspended solids input channel.
Note – By selecting Unit Alarm in the setpoint channel option each alarm option will activate if they
occur on any of the instruments three sensor input channels.
