Viceroy Installation Instructions
6 | Page
FINISHING THE INSTALLATION
• Loosen the 2 screws from the bottom of the mounting bracket.
• Slide the canopy up to the mounting bracket and place the key hole on the canopy over the screw on the mounting
bracket. Turn the canopy until it locks in place at the narrow section of the key holes and secure it by tightening the
2 set screws. Avoid damaging the electrical wiring prepared previously.
BLADE INSTALLATION
• Secure the blade to the motor by tightening the 3 blade screws. Fig.7
• Repeat to install the other blades to the motor.
• Finally, install the bottom cover to the motor shaft by rotating it clockwise. Fig.8
