363-205-401 RT Turn Up: NTP-003
Issue 7, March 1997 Page 3 of 8
DO ITEMS BELOW IN ORDER LISTED FOR DETAILS, GO TO
NOTE:
The term "facility shelf" is used throughout this procedure to
refer to the middle shelf in the Series 5 RT. The remaining
shelves will be referenced according to digroup name (for
example, AB shelf contains digroups A and B). White system
refers to the two upper shelves of the Series 5 RT plus the
right half of the facility shelf and blue system refers to the
two lower shelves of the Series 5 RT plus the left half of the
facility shelf.
Install 3-type protectors in protector panel for shelf group(s) being
equipped.
DLP-5004. Verify, per work order, that the correct complement of circuit
packs is available.
5. If the blue (lower) system is being equipped continue with Step
6
.
Otherwise, to equip the white system, proceed to Step
9
.
DLP-5016. If required [the LFU is required if AUA62( ) line powering LIUs are
used], install and check fuses in
LFU
(line fuse unit) in facility
shelf.
DLP-5027. Install and test
PCU
(power converter unit) in facility shelf.
8.
NOTE:
The 4A fan does not require the FCU but should be tested by
pressing the test button (at least 3 times) and verifying the
fan runs fast, slow, and stops.
DLP-503Install
FCU
(fan control unit) [if
2( ) FAN UNIT
is installed].
DLP-5049. Install and check fuses in
CFU
(channel fuse unit).
