RT Turn Up: NTP-003 363-205-401
Page 4 of 8 Issue 7, March 1997
DO ITEMS BELOW IN ORDER LISTED FOR DETAILS, GO TO
10.
NOTE:
The choice
ADU, BCU, TRU,
and
LIU
determines the
Feature Package configuration of the RT system.
Install
ADU
(alarm display unit) optioned for
pre-service and
unequipped
, install
BCU
, and then change the
ADU
options to
pre-service and equipped
:
DLP-505A.
AUB21 ADU
[Feature Package A (FPA) using MC97723A1
or MC97756A1 BCU).
DLP-505B.
AUB24 ADU
(FPB Mode 1 using MC97724A1,
MC97771A1, or MC97776A1 BCU. FPB Mode 2 with
MC97771A1 or MC97776A1 BCU. No special service).
DLP-506C.
AUB27 ADU
[FPB Mode 1 or Mode 2 with special service,
and FPC-Autocut using MC97771A1 or MC97776A1 BCU.
Feature Package F FPF (ADU optioned as FPC) using
MC97779A1 BCU.]
DLP-507D.
AUB26 ADU
[FPC or Feature Package D (FPD) using
MC97756A1 BCU.]
DLP-50911. Install and test
PCU
in AB shelf.
DLP-51012. Install
TRU
(transmit/receive unit) in AB shelf.
DLP-51113. For FPD only, install
TCU
(transcoder unit) in
LIU-B
slot in facility
shelf.
14.
NOTE:
All
LIU
s in the same system should have identical option
switch settings.
DLP-512Install DS1
LIU
(line interface unit) in
LIU-A
slot in facility shelf
after making option, equalizer, and transmit pad settings.
To Next Page
