363-205-401 RT Turn Up: NTP-003
Issue 7, March 1997 Page 5 of 8
DO ITEMS BELOW IN ORDER LISTED FOR DETAILS, GO TO
15.
NOTE:
All
LIU
s in the same system should have identical option
switch settings.
NOTE:
FPB Mode 2 does not require an LIU in LIU-B slot. FPD
requires a TCU in LIU-B slot.
DLP-512Install DS1
LIU
in
LIU-B
slot in facility shelf after making option,
equalizer, and transmit pad settings for FPA, FPB Mode 1, FPC,
or FPC-AutoCut, or FPF.
16. If equipping shelves CD in the dual bank assembly, continue with
Step
17
. Otherwise, proceed to Step
23
.
17. Install (if not previously installed) 3-type protectors in protector
panel for shelf group(s) being equipped.
DLP-51318. Install
PCU
in CD shelf.
DLP-51419. Install
TRU
in CD shelf.
DLP-51120. For FPD only, install
TCU
(transcoder unit) in
LIU-D
slot in facility
shelf.
21.
NOTE:
All
LIU
s in the same system should have identical option
switch settings.
DLP-512Install DS1
LIU
in
LIU-C
slot in facility shelf after making option,
equalizer, and transmit pad settings.
To Next Page
