300 SERIES ADJUSTABLE BASE
OWNER'S MANUAL
09
08
Assembly
Open the carton in the at
position, buttom facing
up, to avoid damage.
Two people are
required to assemble
this adjustable base.
2.1.
NOTES
STEP 3
Two (2) legs are already installed on the
base. To install the remaining four (4) legs,
thread the bolt of the leg into the frame
and tighten by hand. There are two
locations per leg for user preference.
STEP 2
Open the accessories box and ensure all
accessories are included (see pages 6-7).
STEP 1
Remove folded bed base from the box and
carefully unfold the base. Set it mattress
side down on the oor.
STEP 4
Uncoil the input power cord (connected
to the control box on the underside of the
base) and plug it into the power supply box.
Take caution to avoid pinning ngers or
any underside wires along the hinge.
i
STEP 5
Uncoil the power cord (that has a wall
outlet connection) and attach it to the
power supply box opposite the cord
attached in Step 4.
To Next Page
