Model 12-4 Technical Manual Section 10
Ludlum Measurements, Inc. Page 10-2 May 2016
Reference Description Part Number
Q1 MMBT3904LT1 05-5841
Q2 MMBT4403LT1 05-5842
Q3-Q4 MMBT3904LT1 05-5841
VR1 LT1460KC53-2.5 05-5867
VR2 TPS76038 05-5912
U1-U3 MAX4542ESA 06-6453
U4-U5 CMXT3904 05-5888
U6 CMXT3906 05-5890
U7 MAX4541ESA 06-6452
U8 MAX985EUK-T 06-6459
U9 CD74HC4538M 06-6297
U10 LMC7111BIM5X 06-6410
U11 LT1304CS8 06-6394
U12 MIC1557BM5 06-6457
U13 LMC7111BIM5X 06-6410
U14 TPS76050 05-5913
U15 CMXT3906 05-5890
U16 MAX4541ESA 06-6452
CR2 CMSH1-40M 07-6411
CR3 CMPD2005S 07-6468
SW1 CENTRAL-2P6P 08-6761
SW2 TP11LTCQE 7464-186
SW3-SW4 7101SDCQE 08-6781
SW5 TP11LTCQE 7464-186
R33 250K, 64W254, ×100 09-6819
R34 250K, 64W254, ×10 09-6819
R35 500K, 64W504, ×1 09-6850
R36 250K, 64W254, ×0.1 09-6819
R38 100K, 64W104, HV SET 09-6813
R47 1M, 64W105, NAME 09-6814
R49 10K, 3266×1-103,
HV METER ADJ 09-6822
TRANSISTORS
VOLTAGE
REGULATOR
INTEGRATED
CIRCUITS
DIODES
SWITCHES
POTENTIOMETERS /
TRIMMERS
