Model 12-4 Technical Manual Section 10
Ludlum Measurements, Inc. Page 10-3 May 2016
Reference Description Part Number
R1-R5 200K, 1/8W, 1% 12-7992
R6 8.25K, 1/8W, 1% 12-7838
R7 10K, 1/8W, 1% 12-7839
R8 2.37K, 1/8W, 1% 12-7861
R9-R11 10K, 1/8W, 1% 12-7839
R12 1K, 1/4W, 1% 12-7832
R13 10K, 1/8W, 1% 12-7839
R14 4.75K, 1/8W, 1% 12-7858
R15 249K, 1/4W, 1% 12-7862
R16 10K, 1/8W, 1% 12-7839
R17 1K, 1/8W, 1% 12-7832
R18 4.75K, 1/8W, 1% 12-7858
R19 2K, 1/8W, 1% 12-7926
R20 100K, 1/8W, 1% 12-7834
R21 249K, 1/4W, 1% 12-7862
R22 1M, 1/8W, 1% 12-7844
R23 124K, 1/4W, 1% 12-7032
R24 14.7K, 1/8W, 1% 12-7068
R25 200K, 1/4W, 1% 12-7992
R26 100K, 1/4W, 1% 12-7834
R27 68.1K, 1/8W, 1% 12-7881
R28 100K, 1/8W, 1% 12-7834
R29 1K, 1/8W, 1% 12-7832
R30 100K, 1/8W, 1% 12-7834
R31 475K, 1/8W, 1% 12-7859
R32 100K, 1/8W, 1% 12-7834
R37 200K, 1/4W, 1% 12-7992
R39 1M, 1/4W, 1% 12-7844
R40 10K, 1/4W, 1% 12-7839
R41-R42 100K, 1/4W, 1% 12-7834
R43 10K, 1/4W, 1% 12-7839
R44 1K, 1/4W, 1% 12-7832
R45 475K, 1/4W, 1% 12-7859
R46 10K, 1/4W, 1% 12-7839
R48 1M, 1/4W, 1% 12-7844
R50 1K, 1/4W, 1% 12-7832
P1 640456-5 - MTA100 13-8057
P2 640456-6 - MTA100 13-8095
P3 640456-2 - MTA100 13-8073
RESISTORS
CONNECTORS
