Lufft XA1000 User Manual

31 Operating manual – multifunction measuring meter XA1000 / XP200 / XP400 • 08_2015 GB
Calibration temperature/humidity probe SDI 9130.540 and 9130.520 (XA1000, XP200 only)
A.
140
120
B.
139
141
C.
120 Opens the calibration menu (see fig. B.).
Please note that the calibration menu indicated is always that
of the top measurement channel, in this case the temperature
(see fig. A.).
For humidity calibration, see fig. D. on the following page.
139 Current measured value indication
140 CAL (offset/single-point calibration):
Use this button to enter an offset value (see fig. C.).
Please observe the limit values.
141 Returns to the "Measuring mode" screen.

Lufft XA1000 Specifications

General

Brand	Lufft
Model	XA1000
Category	Measuring Instruments
Language	English
