Lumenier LUX - Connect Battery (Main Power connection); Connect OSD (On Screen Display); Connect GPS

6
Connect LED Strip
You can connect an addressable LED strip (WS2812B) to the
LUX
flight controller. Connect your
LED strip to pins labeled
12
.
Enable feature in CLI:
feature LED_STRIP
Connect Battery (Main Power connection)
Your
LUX
flight controller has input voltage 6-26v (2-6S lipo). Connect main power lead to pins
labeled
10
.

Always check the polarity before plugging in. There is no reverse polarity protection.
Enable feature in CLI:
feature VBAT
Connect Current Sensor
Connect a current sensor signal wire to the pin labeled
9
, and corresponding GND wire.
Enable feature in CLI:
feature CURRENT_METER
current_meter_type 1
Connect OSD (On Screen Display)
You can connect a compatible OSD to your
LUX
flight controller. Connect the corresponding
TX
and
RX
pins to USART1 labeled Pin
7
.

For MWOSD and similar OSD, remember to change Voltage/Amperage/RSSI to “Use FC”.
Connect RSSI
Connect RSSI pin from your receiver to
LUX
pin
11
Connect GPS
GPS features in Cleanflight are experimental. Please share your findings with the developers. GPS
works best if the GPS receiver is mounted above and away from other sources of interference.
Connect GPS TX/RX/5v/GND pins to corresponding
TX
and
RX
pins (TX to RX, RX to TX) labeled
5, 6, 7, 8
.
Enable feature in CLI:
feature GPS
set gps_provider = 0 (nmea only)
set gps_provider = 1 (UBLOX only)
