LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 6
4 FEATURES
COMPONENTS
Item Description Quantity
Base preassembled with footplate and casters 1
Side support arm unit 2
Kneepad assembly 1
Seat pad and handle bar support unit with cross
bar tube
2
FASTENERS AND TOOLS
No. Item Description Quantity
A1 Carriage bolt 8
A2 Hex bolt 2
A3 Button socket head cap screw 4
A4 Flat washer 10
A5 Lock washer 10
A6 Acorn nut 8
A7 Plastic cap 2
T1 Wrench 1
T2 Hex key 1
