RJ4700-INS-LAB-RevB12
2
rear leg and wheel,
handle and brake cable
(2 each)
seat, seat frame, and
pouch (1 each)
back bar
(1 each)
triangular knob
(4 each)
quadrangular knob
(2 each)
front leg
and wheel
(2 each)
Unless the Rollator is to be used immediately, retain box and packaging materials for storage until
use is required.
1. Carefully remove all components from the carton.
2. Inspect all components (shown above in g. 1).
3. If damage is evident to the contents, please notify the carrier and your Graham-Field authorized
distributor.
Refer to pictures at right during assembly.
Info: As shown in fig. 2, each frame leg tube has a
number corresponding to one of the four legs. Match
each number at upper end of leg to each number on
frame tube.
Info: Consult your healthcare professional to
determine proper seat height adjustment.
assembly
match number
